Lenovo ThinkSystem SR630 V3
Description
- Model: ThinkSystem SR630 V3
- Brand: Lenovo
- Form Factor: 1U rack
- Processor: 2x Intel® Xeon® processor, up to 64 cores
- Memory: Supports up to 32x TruDDR5 3DS/RDIMMs
- Disk Bay: up to 4x 3.5” or 10x 2.5”
- GPU Support: Up to 3x single-width 75W GPUs
- PCIe: Up to 5x PCIe 4.0/5.0 slots
- RAID: SATA with SW RAID (0,1,5,10); including standard and Internal PCIe RAID/HBA adapters
- Network Interface: LOM adapter installed in the OCP 3.0 slot, optional for front access Networking PCIe adapters
- Ports: Front: 1x USB 3.1 G1, 1x USB 2.0 for BMC, 1x VGA (optional), 1x external diagnostics handset port (optional)
- Security: ROT module with integrated PFR, BMC, TPM, and EEPROMs
- Systems Management: ThinkSystem XClarity Controller
- Power Supplies: Redundant PSU
- OS Support: Scale HyperCore
- Warranty: 3-year warranty with the option to upgrade to years 4 & 5
